X-76cc-T PRO
Displacement: 76cc (4.64 cu in)
Performance: 9.0 HP
Speed Range: 1800-7300 RPM (Test Propeller-24*9)
Bore: 39 mm (1.54 in)
Stroke: 32.5mm (1.28 in)
Static Thrust: 18.5 kg @ 100 m ALT (40.8 lb @ 328 ft ALT)
Static Thrust: 16.8 kg @ 1800 m ALT (37.1 lb @ 5900 ft ALT)
Compression ratio: 9:1
Lubrication ratio: 30:1 (Fuel: 2-Stroke Motor Oil)
Ignition Voltage: 6-14 V
Spark Plug Type: CM6 Iridium Spark Plug
Recommended Propeller: 22x10; 23x8; 23x10; 24x8
Weight of Main Engine: 1935g
Weight of Muffler Set: 174g (L&R Mufflers; Screws)
Weight of Engine Mount: 72g
Weight of Spark Plug: 13.5g *2 (CM6*2)
Weight of CDI (Ignition): 173g
Weight of Starter: 123g
Weight of ESC: 36g
Total Weight: 2417g (5.3 lb)
